The EVENT-218A dual 18” powered subwoofer makes use of one of DAS´s most acclaimed loudspeakers, the LX series long excursion transducers which were introduced in the high-level LX-218. The enclosure is designed for horizontal use, built using quality Birch plywood, finished with the ISO-flex coating and has a pole mount socket on the upper panel.

The power amplifier provides 3600 W peak power and offers features found on the more expensive LX subwoofers such as the Cardioid Preset mode switch which offers specific signal treatment for easy set-up of pairs of systems in cardioid subwoofer applications. The system includes two balanced inputs (A-B) with stereo HPF (100 Hz) filtered output connections for satellite systems. Defeating the HPF filter offers stereo “loop thru” connections. The variable LPF crossover ranges from 80 Hz-125 Hz. A gain control and polarity reverse feature increase user control over the system.

Performance

• Frequency Range (-10 dB): 32 Hz – 125 Hz
• Maximum Peak SPL at 1 m: 140 dB

Electronics and Connectors

• Nominal Amplifier Power (continuous): 1800 W
• Nominal Amplifier Power (peak): 3600 W
• Input Type: Balanced
• Input Impeadance: 20 kohms
• Input Sensitivity: 6.2 V (+18 dBu)
• Audio Signal Input Connector:  2 x Female XLR
• Audio Signal Loop Thru Connector: 2 x Male XLR
• AC Input Connector: powerCon NAC3FCA
• AC Output Connector: powerCON NAC3FCB
• Operating Range: 90-250 VAC
• Current Draw 115 V : 6.0 A
• Current Draw 230 V : 3.0 A
• Certification Number: NRTL US&CA SGSNA/19/SUW/00110

Enclosure

• Enclosure Construction: Birch Plywood
• Enclosure Geometry: Rectangular
• Rigging: M10 Rigging Points
• Finish: ISO-flex Paint
• Color: Black
• Dimensions ( H x W x D ): 550 x 1.065 x 675 mm; 21,7 x 41,9 x 26,6 in
• Net Weight: 68,5 kg ( 151,0 lb )

Components

• LF Driver: 18LX

Shipping

• Carton Dimensions ( H x W x D ): 1.180 x 730 x 610 mm; 46,5 x 28,7 x 24,0 in
• Shipping Weight: 73,5 kg ( 162,0 lb )
