Inspire your audience. Go for XS WIRLESS 1 and rely on a solid wireless transmission with up to 10 compatible channels in a stable UHF band. The XS WIRELESS 1 LAVALIER MIC SET is an easy to use all-in- one wireless system for presenters and moderators, excellent for a powerful and inspiring presentation. The set includes an intuitive stationary receiver for quick set-up and hassle-free handling, as well as a lightweight bodypack transmitter and an unobstrusive clip-on microphone.

Receivers

• Dimensions
  • 200 x 42 x 127 mm
• Weight
  • 340g
• Power supply
  • 12 V DC nom. / 300 mA
• AF frequency response
  • 50 to 16,000 Hz (–3 dB)

Transmitter

• Dimensions
  • 71 x 96 x 28 mm
• Weight
  • 95g
• Power supply
  • 2 AA size batteries, 1.5 V
• Adjustment Range Transmitter
  • 0 to -30 dB, adjustable in 10 dB steps
• Microphone
  • condenser
• THD, total harmonic distortion
  • ≤ 0.9%
• Pick-up pattern
  • omni-directional
• Signal-to-noise ratio
  • ≥ 103 dBA
• RF output power
  • 10 mW
• Switching bandwidth
  • up to 24 MHz
• Operating time
  • 10 hrs
• Modulation
  • wideband FM
• Output voltage
  • '1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
• Housing
  • rugged ABS housing
• Diversity reception
  • antenna switching diversity via internal antennas
• Frequency
  • 8 frequency banks, each with up to 10 factory-preset channels
• Frequency range
  • A: 548-572 MHz, GB: 606-630 MHz
  • B: 614-638 MHz, C: 766-790 MHz
  • D: 794-806 MHz
  • E: 821-832 MHz, 863-865 MHz
  • K: 925-937.5 MHz
• Sensitivity
  • < 3 μV at 52 dB(A)rms S/N
• SPL for peak deviation
  • 130 dB
• Squelch
  • adjustable from 3 dBμV to 28 dBμV (combined with pilot tone)
• Synchronization
  • 4 GHz, Low Power OQPSK (only active during synchronization)
• Input sensitivity
  • 5 mV / Pa
• Audio adjustment range
  • 45 dB, adjustable in 5-dB steps
• Line / Mic level
  • 20 dB, switchable
• Temperature Range
  • operation: 0°C to +40°C, storage: –20°C to +70°C
• Receiver Principle
  • double superheterodyne
