Launched in 1995, JBL’s best-selling EON family of PAs set the benchmark for how great a powered loudspeaker system can be.

The JBL EON715 15-inch loudspeaker is part of JBL’s new EON700 Series of powered PAs, which represent a major step forward in innovation and technology: JBL engineers used exclusive, state-of-the-art design and measurement techniques to deliver the best-performing loudspeakers in their category, regardless of application.

The EON700 Series leverages the latest acoustic science, transducer designs, cabinet materials and advanced DSP and control technologies to deliver extraordinary performance in a fully professional, highly flexible, easy to use, portable system.

FEATURES

• Custom-designed 15-inch woofer
• 2414H-1 compression driver
• Re-designed high-frequency horn
• Power: 1,300W peak / 650W RMS
• Frequency response: 45 Hz–20 kHz (-10 dB); 55 Hz–20 kHz (-3 dB)
• Advanced dbx DSP: Automatic Feedback Suppression, ducking, 100ms speaker delay, parametric EQ
• Built-in 3-channel digital mixer
• Backlit color LCD screen provides easy access to functions
• Universal JBL Pro Connect app control
• Bluetooth 5.0 streaming and control
• Durable polypropylene cabinet and metal grille
• Two ergonomic handles simplify transport
• Built-in pole mount and optional EON700 Universal Yoke Mount expand system configuration options
• Stackable cabinets allow easy storage

• System Type: 15IN Powered Loudspeaker
• Woofer Model: 715G
• Woofer Sizer: 15"
• Woofer Magnet: Ferrite
• Woofer Voice Coil: 2"
• Tweeter Model: 2414H Compression Driver
• Tweeter Size: 1"
• Tweeter Magnet: Neodymium
• Transducer Impedence: LF 4ohm rated, HF 8ohm rated
• MAX SPL: 128dB @1m/4Pi
• Freq Range -10: 45Hz - 20kHz
• Freq Range -3: 55Hz - 20kHz
• Hor Dispersion: 90°
• Vert Dispersion: 60°
• Power Rating: 1300W peak / 650 RMS
• AC power input: 100V-120V or 220V-240V
• Cooling: Passive
• LED indicators: 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs
• Input Impedance: 50k/100k un-balanced/balanced
• Input Gain: -∞to +36db
• Crossover Frequency: 1.9 kHz
• I/O: 2 XLR Combo Jacks / BT
  1 XLR M Thru
• Cabinet: PP+10% Talc
• Grille: 16GA perforated steel with acoustically transparent black cloth backing
• Suspension / Mounting: 4 M10 Suspension points, 36mm Pole Socket, universal yoke bracket holes
• Handles: 2, cable channel on bottom
