Yamaha MG20Xu 20 Channel Effects Mixer

The Yamaha MG20XU analog mixer is suitable for portable installations or permanent installations, rich in features and exceptional sound quality. The MG20XU series operational amplifier ensures that your mix sounds transparent and articulated. The MG20XU's clear crystal D-PRE pre amplifiers will squeeze every drop of tone from the microphones, with natural and soft bass.

It has digital effects, switchable phantom power, pad switch, single knob compressors, EQ, lots of Inputs / Outputs, and LED measurement, the MG20XU can assume almost any task assigned. Using many cutting-edge features of Yamaha's high-end consoles, the MG20XU is ready to work!

• 20-Channel Mixing Console
• 16 Mic / 20 Line Inputs (12 mono + 4 stereo)
• 4 GROUP Buses + 1 Stereo Bus
• 4 AUX (incl. FX)
• “D-PRE” mic preamps with an inverted Darlington circuit
• 1-Knob compressors
• High-grade effects: SPX with 24 programs
• 24-bit/192kHz 2in/2out USB Audio functions
• Works with the iPad (2 or later) through the Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter
• Includes Cubase AI DAW software download version
• PAD switch on mono inputs
• +48V phantom power
• XLR balanced outputs
• Internal universal power supply for world-wide use
• Rack Mount Kit Included
• Metal chassis
• Dimensions(W×H×D): 444 mm x 130 mm x 500 m (17.5" x 5.1" x 19.7")
• Net Weight: 7.1kg (15.7 lbs.)
